SANSUN
Operating Principles
sanitary pneumatic butterfly valve single acting Air Spring
Pneumatic clamp butterfly valve can be automatically operated by actuator
The actuator push piston of axial movement into 90 degree so that it controls butterfly valve.
The butterfly valves used in beer, beverage, dairy, fruit juice, pharmacy, bioengineering and other fields.
Technical Specifications
Max.pressure: 10 bar (DN-25/100);8 bar (DN-125/150)
Min.pressure: 0.2 bar p.abs
Operating temperature:-10℃ to +120℃ (EPDM)
Materials
Butterfly plate: AISI316L/304(forged)
Valve body: AISI316L/304(forged)
Surface finishing: Ra=0.8
Standard Design
Available in sizes from DN15 / 1/2" to DN100 / 3"
Standard Avaliable: DIN, SMS, ISO, IDF, RJT, IDF, 3A
Connection: weld, clamp, thread, single weld single thread, flange
Actuator: pneumatic stainless steel actuator, pneumatic aluminum actuator, electric actuator
Control: position sensor, C-TOP controller, C-TOP controller(AS-I)
Butterfly Valves Curve
Different Drive Way of Pneumatic Butterfly Valve
Exploded view of Intelligent pneumatic butterfly valve
Inspection
All kinds of non-standard products are customized according to the requirements of customers. Products can be traced back to the
manufacturing and time of each process to ensure the quality of products.
