| Size | DN25-DN100(1''-4'') |
| Valve Body Material: | AISI304/AISI316L ,1.4404/1.4301 (Forged) |
| Valve Disc Material: | AISI304/AISI316L ,1.4404/1.4301 (Forged) |
| Seal Material: | EPDM, PTFE, Viton, Silicone |
| Surface Finishing： | Ra < 0.4-0.8 µm (32 µin) |
| Max Working Pressure: | 145psi (10bar) |
| Helium Leak Test: | <1 × 10⁻⁹ mbar・l/s |
| Cleanliness: | Passivation treatment, Conforms to ASTM A380 standard |
| Availably standard: | DIN/3A/SMS |
| Connection type | Clamp End,Weld End |
| Certification | US 3-A, FDA, CE PED/2014/68/EC, Certification |
| Application scope: | Designed for AI data center liquid cooling systems including OCP cold plate CDU and server cooling loops also widely used in food beverage brewery pharmaceutical and fine processing sanitary piping to prevent fluid backflow
|
