| Size | DN25-DN100(1''-4'') |
| Valve Body Material: | AISI304/AISI316L ,1.4404/1.4301 (Forged) |
| Valve Disc Material: | AISI304/AISI316L ,1.4404/1.4301 (Forged) |
| Surface Finishing： | Ra < 0.4-0.8 µm (32 µin) |
| Max Working Pressure: | 145psi (10bar) |
| Helium Leak Test: | <1 × 10⁻⁹ mbar・l/s |
| Cleanliness: | Passivation treatment, Conforms to ASTM A380 standard |
| Ofcores： | Metal Mesh,Pertorated Plate,Wedge Wire |
| Connection type | Clamp End,Weld End,Threaded End |
| Certification | US 3-A, FDA, CE PED/2014/68/EC, Certification |
| Application scope: | Sanitary Stainless Steel Jacketed Tri-Clamp Elbow is a thermal insulation pipe fitting with outer heat jacket structure. Steam or hot water can circulate inside the jacket to keep constant temperature of medium in pipeline, preventing chocolate, syrup, cream and other viscous materials from solidifying. Adopt tri-clamp connection for fast installation and disassembly, widely used in food, confectionery, dairy and pharmaceutical processing lines.
|
