Sanitary Mixproof Valve Manifold Stainless Steel Anti-Mixing Valve Matrix For Food Beverage Pharmaceutical

Share to:

Sanitary Mixproof Valve Manifold Stainless Steel Anti-Mixing Valve Matrix For Food Beverage Pharmaceutical

Our sanitary mixproof valve manifold is a modular integrated fluid control system made of high-quality 304/316L stainless steel. Adopting professional double-seat anti-mixing structure with independent leakage chamber, it effectively prevents cross-contamination between different media and ensures high sanitary safety for production lines. Designed for simultaneous production and CIP cleaning, this valve manifold supports independent pipeline switching and online sterilization without frequent shutdowns, greatly improving production efficiency. With smooth mirror polishing internal surface and no sanitary dead corners, it fully meets FDA, 3-A and food-grade hygienic standards. Compact modular structure enables customized valve combinations, flexible pipe connection modes and easy installation and maintenance. Widely used in dairy, beverage, brewery, pharmaceutical and cosmetic industries for hygienic fluid processing systems.

Size:	1" 1 1/2" 2" 2 1/2" 3" 4" DN40 DN50 DN65 DN80 DN100
Material:	SS304 SS316L
Availability:

Quantity:



Inquire Add to Basket

Brand:
SANSUN

Product Description

Size	1 1/2''-4''(DN40-DN100)
Material:	AISI304/AISI316L ,1.4404/1.4301 (Forged)
Seal Material:	EPDM, Silicone, FKM, FFKM, TEFLON, PTFE, HNBR, NBR, FDA approved
Surface Finishing：	Ra < 0.4-0.8 µm (32 µin)
Max Working Pressure:	145psi (10bar)
Helium Leak Test:	<1 × 10⁻⁹ mbar・l/s
Operation:	pneumatic actuator+ ControlTOP
Pipe Joint Systems:	DIN/3A
Connection type	Tri-Clamp End, Butt Weld End
Certification	US 3-A, FDA, CE PED/2014/68/EC, Certification
Application scope:	SANSUN's sanitary mixproof valve manifold is forged from 304/316L stainless steel. Its double-seat structure with leakage chamber avoids medium cross-contamination. It enables parallel production and CIP online cleaning to cut downtime. Mirror polished inner surface (Ra 0.4–0.8μm) complies with 3-A & FDA standards. Modular design with tri-clamp/butt weld connections, easy to install and maintain. Widely applied in dairy, beverage, craft brewery, pharmaceutical and cosmetic hygienic fluid production lines.
