SANSUN
SS-V801
Operating Principles
The Air Release Valve wit Spring return are adjustable, exactly adjust to opening pressure,
the valve is open and closed sensitively with small differ pressure.
Available in open design(free blowing-off of air) and closed design(collect the excess air).
This valve with stainless steel materals,hygienic design,
applied to all kinds of,food processing,drink,and pharmaceutical and other industrial fields.
Technical Specifications
Max. Working Tem.:121 Degree C/250 Degree F
Set Pressure : 0.2 to 2.2 bar
Materials
Valve body: AISI316L/304
Gasket Material: Silicon, EPDM, VITON,Teflon (PTFE)
Standard Design
Available in size: 1",1 1/4", 1 1/2" Or DN25, DN32, DN40
Standards: DIN, SMS, ISO / IDF, BS / RJT, ASME / BPE.
End connections: Tri-Clamp, Liner&Nut, Weld, Threaded or others upon request
Corresponding size can be provided upon request
Clamp Air Relief Valve Applicable Occasions
Inspection
All kinds of non-standard products are customized according to the requirements of customers. Products can be traced back to the
manufacturing and time of each process to ensure the quality of products.
