SANSUN
Operating Principles
The diaphragm valves can be operated automatically through actuator or manually with the handwheel.
The handwheel blocks the valve in the "open" or "closed"position, certainly there are the other position available.
The closing and opening of the actuator is realized by the pressure from the pipeline acting on the reinforced rubber diaphragm.
The diaphragm valves used in beer, beverage, dairy, fruit juice, pharmacy, bioengineering and other fields.
Technical Specifications
Max.pressure: 147psi (10bar)
Operating temperature:-10℃ to +120℃ (EPDM)
Available for CIP/SIP
Materials
Valve body: AISI316L/304
Diaphragm: EPDM+PTFE or EPDM
Standard Design
Available in sizes from 1" to 2"
Standard Avaliable: DIN, SMS, ISO / IDF, BS / RJT, ASME / BPE
Connection: weld, clamp, or others upon request
Body type: T-type tee, U type tee, Mini type, tank bottom type, etc
The Diaphragm of Diaphragm Valve
Diaphragm Valve Anatomy Diagram
Exploded view of Diaphragm Valve with Handwheel
Inspection
All kinds of non-standard products are customized according to the requirements of customers. Products can be traced back to the
manufacturing and time of each process to ensure the quality of products.
