| Size | 1 1/2"-4" (DN40-DN100) |
| Valve Body Material: | AISI304/AISI316L ,1.4404/1.4301 (Forged) |
| Valve Disc Material: | AISI304/AISI316L ,1.4404/1.4301 (Forged) |
| Max Working Pressure: | 145psi (10bar) |
| Helium Leak Test: | <1 × 10⁻⁹ mbar・l/s |
| Cleanliness: | Passivation treatment, Conforms to ASTM A380 standard |
| Specification： | 1T-500T.0.55kw-55kw
|
| Seal: | single seal (standard）,double mechanical seal （option）SIC/C.SIC/SIC
|
| Connection type | Clamp End,Flange,Weld End |
Motor brand： | ABB motor ，Simens
|
| Application scope: | This stainless steel tri-lobe rotary lobe pump is designed for sanitary conveying of dairy, jam, cream and other high-viscosity materials, with 304/316L stainless steel body and CIP cleanable structure.. |
