| Size: | 1/2"-6" (DN10-DN150) |
| Valve Body Material: | AISI304/AISI316L ,1.4404/1.4301 (Forged) |
| Vale Disc Material: | AISI304/AISI316L ,1.4404/1.4301 (Forged) |
| Seal Material: | EPDM,PTFE,NBR |
| Surface Finishing: | Ra ≤0.4 µm |
| Max Product Pressure: | 1600Kpa (16bar) |
| Operating Principles: | Driven by the actuator stem 90° rotation,drive the precise manufacturing ball body which with through cavity,turn on or off, so that can control the medium flow. |
| Availably standard: | DIN/3A/ISO |
| Connection type: | Clamp End,Thread End,Weld End |
| Pneumatic Operation: | Sensor,Pneuamtic actuator(single acting,double acting),electric actuato,C-TOP, C-top controller(AS-1） |
| Certification: | US 3-A, FDA, CE PED/2014/68/EC, Certification |
| Application scope: | Sansun's butterfly valve is suitable use for sterile media transfer in pharmaceutical lines,Milk, juice, beer, and syrup processing,CIP chemical solution distribution,water for injection (WFI) and pure steam systems. |
